Features:
- High resolution AC current measurement
- Temperature measurement to 1832°F (1000°C)
- 4000-count LCD display with backlight
- Data Hold and Zero function
- Diode test and continuity buzzer
- EN61010-1 Cat. III 600V
- Complete with AD-1 temperature input adapter,
TP-01 type K thermocouple wire probe, TL-88-1
test leads, AM-4 batteries and C-820 carrying case
Specifications:
- AC Current Range: 400.0, 4000μA, 4.000, 40.00, 400.0A
- AC Voltage Range: 400.0mV, 4.000, 40.00, 400.0, 600V
- DC Voltage Range: 200.0mV, 2.000, 20.00, 200.0, 600V
- Resistance Range: 400.0Ω, 4.000, 40.00, 400.0kΩ,
4.000, 40.00MΩ
- Capacitance Range: 40.00, 400.0nF, 4.000, 40.00,
100.0μF
- Frequency Range: 5.000, 50.00, 500.0Hz, 5.000, 50.00,
150.0kHz
- Temperature Range: -58 to 1832°F (-50 to 1000°C)
- Duty Cycle: 0.5 to 99.0%
- Power Supply: 2 x "AAA" 1.5V batteries
- Jaw Opening: 0.9" (23mm)
- Dimensions: 8.1 x 2.75 x 1.5" (205 x 70 x 37mm)
- Weight: 7.1 oz (200g)
|
 |
